The CP Plus CP-UNS-7216DR-V3 is a high-performance Surveillance Management Centre (SMC) designed for large-scale CCTV deployments. It is a robust enterprise-grade server capable of handling thousands of cameras, AI-powered analytics, access control, and video intercom systems.
This “NEW” model features an Intel i5-12400 processor, 16GB RAM, redundant power supply, and massive storage support — making it ideal for smart cities, large campuses, industrial complexes, airports, and central monitoring stations.
Product Link: CP Plus CP-UNS-7216DR-V3
Key Specifications
| Feature | Details |
|---|---|
| Processor | Intel Core i5-12400 (6 Core, 64-bit) |
| Operating System | Embedded Linux |
| Memory | 16 GB |
| System Disk | 6 TB Enterprise HDD (Seagate) |
| HDD Support | Up to 15 HDDs (3.5″), Hot Swap Support |
| Maximum Storage | 200 TB per server |
| Power Supply | 1+1 Redundant Power |
| Network Ports | 4 × Gigabit Ethernet (100/1000 Mbps) |
| Video Output | 4 × HDMI + 1 × VGA |
| USB Ports | 2× USB 2.0 (Front) + 2× USB 3.0 (Rear) |
| Incoming Bandwidth | 600 Mbps (per server) |
| Max Devices | 2,000 devices (Single Server) / 6,000 (Multi-server) |
| Storage Bandwidth | 600 Mbps |
| Key Features | AI Target Search, GIS Mapping, Access Control, Video Intercom, ONVIF |
| Operating Temperature | 0°C to +40°C |
| Dimensions & Weight | 444.8 × 133.2 × 522.2 mm, 19.1 kg |
Design & Build Quality
This is a rack-mountable (2U or 4U form factor) heavy-duty server with a professional industrial design. It supports hot-swappable HDDs and 1+1 redundant power supplies, ensuring high uptime and reliability — critical for 24×7 surveillance operations.
The front panel displays system service status, which is very useful for quick monitoring.
Installation & Setup
This is an enterprise product and requires professional installation:
- Rack mounting in a server room or control centre.
- Connect multiple IP cameras, access control devices, and intercom systems via ONVIF.
- Configure storage (local + IP-SAN support).
- Set up EVMS Pro software for central management.
It supports multi-server clustering for even larger projects (up to 6,000 devices).
Key Features Performance
- High Scalability — Handles thousands of cameras and devices with excellent bandwidth.
- AI Capabilities — AI-powered target search, movement analysis, face recognition support, and metadata search.
- GIS & Mapping — Supports Google Maps and Raster Maps for location-based monitoring.
- Unified Management — Integrates Video Surveillance, Access Control, Video Intercom, ANPR, People Counting, and more in one platform.
- Redundancy — Redundant PSU + hot-swap drives minimize downtime.
- Massive Storage — Up to 200 TB per server with high write performance.
Pros
- Very high storage capacity (200 TB per server).
- Redundant power supply for reliability.
- Strong AI and intelligent search features.
- Excellent multi-system integration (Video + Access + Intercom).
- High incoming/outgoing bandwidth.
- Hot-swappable HDDs.
- Supports large-scale deployments and multi-server setups.
Cons
- Expensive enterprise-grade product (not for small homes/SMEs).
- Requires professional setup and technical expertise.
- Higher power consumption (up to 315W).
- Heavy and needs a proper server room environment.
- Learning curve for the full EVMS Pro software.
Who Should Buy It?
- Large enterprises and corporates.
- Smart City projects.
- Airports, Metro stations, and Transportation hubs.
- University campuses and industrial plants.
- Central monitoring stations for security integrators.
- Government and law enforcement projects.
Best paired with: High-end CP Plus IP cameras, Mobile NVRs, and Access Control systems.
Final Verdict (Rating: 9.2/10)
The CP Plus CP-UNS-7216DR-V3 is a powerful and future-ready Surveillance Management Centre. With massive storage, redundant design, AI features, and excellent scalability, it is one of the strongest options for large-scale professional surveillance projects in India.
If you need a reliable central server for hundreds or thousands of cameras with unified management, this is a highly recommended choice.
